STARTING AT
Full Details
Front Shape
Flat Front - Cast Corner
Box (LxW)
16' x 8.5'
Interior (LxWxH)
15' 10" x 97" x 84"
Overall (LxWxH)
21' 6" x 102" x 112"
Rear Door Opening (WxH)
90" x 81"
Deck Height
20"
Hitch Height
19"
Axle(s)- Qty/Rating
2 x 3,500 lb
GVWR
9,900 lb
Curb Weight*
2,200 lb
Payload*
7,700 lb
Ball Size / Coupler Rating
2 5/16" / 10,000 lb
Wheels
15" Aluminum
Tires
ST205/75R15 LRD
Power Connection
7-Way
Frame
Aluminum Tube Construction
6-Sided Welded Frame
3 Year Structural Warranty
Extended Triple Tube Tongue – 49″
16” O/C Floor Crossmembers
16” O/C Wall Crossmembers (400) / ATC Cross-Grid Wall Technology (450)
16” O/C Roof Crossmembers
2” x 5” Subframe Tubing (16’-24’)
2” x 7” Subframe Tubing (28’)
Awning Prep
Rear Spoiler with (3) LED Lights & BU
Brushed Cast Corners with Stainless Steel Trim
Spread Axles with Kick Downs
Beavertail Floor (N/A on 16’)
Winch Plate
Mechanical
Torsion Axles
ST 205 or 225 Aluminum Wheels
Entrance Door – 36” (16’- 24’) or 48” (28’)
Safety Chains
5,000 lb Manual Jack
A-Frame Coupler
4,000 lb Ramp Door
Ramp Transition Flap
Aluminum Bar Locks with Stainless Steel Hasp
12” Slimline Lights
(4) Recessed D-Rings
(1) Manual Roof Vent
Other Construction Detail
One-Piece Aluminum Roof
.030 Screwless Aluminum Exterior
24” Stone Guard
3/8” Engineered Walls with Cove
3/4” Engineered Floor
Open Stud Ceiling
(1) Dome Light with Wall Switch
4” Lower and Upper Trim
Color Matched Rear Header & Verticals
Rōm 450 Series Features (450 Only)
LifeTrac – Modular Track System (Patent Pending)
(2) Window Prep Locations (RS/CS)
(2) 12V USB Cove Ports
Plus Package (Requires Cabinet Package)
Aluminum Ceiling (.030 White) and Sp Cover (Black)
Aluminum Walls – White or Dove Grey
Premium Escape Door
30 Amp Electrical Package
Aluminum Slide Out Step (N/A on 16′)
Required Choice of Cabinet Package
Floor Choice Separate
Premier Package (Requires Cabinet Package)
Aluminum Ceiling (.030 White) and Sp Cover (Black)
Aluminum Walls – White or Dove Grey
Premium Escape Door
50 Amp Electrical Package
Aluminum Slide Out Step (N/A on 16′)
Insulated R3 Walls/R6 Ceiling
40″ Tall Carpet on Walls
(2) Bogey Wheels
Tongue Storage Compartment
Required Choice of Cabinet Package
Floor Choice Separate
Black Trim Package
Black ATP Gravel Guard
Black Upper and Lower Trims
Black Exterior Fasteners on Trim
Black Fenders
Black Wheels
Black Exterior Door Trim
Black Grab Handles and Bar Locks
Black Logos
15 Amp Electrical Package
15 Amp Motorbase Plug
55 Amp Converter
Lithium Battery – 100Ah (Boxed)
(2) Interior Outlets
30 Amp Electrical Package (Requires Cabinet & Ceiling)
30 Amp Breaker Box
Integrated 60 Amp Converter
Lithium Battery – 100Ah
(2) Interior Outlets
Dual USB Port
(1) Exterior Outlet
(4) 49″ LED Lights
(2) CS Scene Lights
25′ Shore Cord
A/C Prep
Required Choice of Cabinet Package
Required Choice of Ceiling
50 Amp Electrical Package (Requires Cabinet & Ceiling)
50 Amp Breaker Box
Integrated 60 Amp Converter
Lithium Battery – 100Ah
(3) Interior Outlets
Dual USB Port
(1) Exterior Outlet
(4) 49″ LED Lights
(2) CS Scene Lights
25′ Shore Cord
A/C Prep
Required Choice of Cabinet Package
Required Choice of Ceiling
Cabinet Package 1
Upper Cabinets
Cabinet Package 2
Upper & Fold Down Counter
Cabinet Package 3
Upper & Lower
Cabinet Package 4
Upper & L-Base/Gen Door
Cabinet Package 5
Upper & Lower w/ Dresser/Drawer Bank
Cabinet Package 6
Upper & L-Base/Gen Door w/ Dresser/Drawer Bank
Cabinet Package 7
Upper & 30” Lower w/ Storage Box/Door/Slide
Cabinet Package 8
Upper & 30” Lower w/ Storage Box/Door/Slide w/ Dresser/Drawer Bank
Base Model Enhancements
Add 6″ Interior Height
Premium Escape Door (N/A with RS Window)
Tie Down Options
(2) Airline Tracks in Floor – Partial – Recessed
Tire and Wheel Options
Interior Wall Spare Tire Mount
Spare Tire 205 on Steel or Aluminum
Spare Tire 225 on Steel or Aluminum
Electrical – Lighting Options
(2) or (4) 49” Light Bar on Ceiling
(1) LED Porch Light with Switch
(2) 12V Scene Lights (Roadside or Curbside)
(2) 12V Docking Lights
Electrical – Miscellaneous Options
Additional Lithium Battery – 100Ah (Requires Electrical Package)
Solar Battery Trickle Charger (30W)
AM/FM/MP3 Stereo with Interior & Exterior Speakers
Backup Camera
Heating and Cooling Options
(2) Flow Through Sidewall Vents
(1) 12V Powered Roof Vent (Front)
A/C 13,500 BTU with Heat Strip
A/C 15,000 BTU with Heat Pump & Thermo
Ceiling and Wall Options
Aluminum Ceiling (.030 White) & Sp Cover (Black)
Aluminum Walls (.030 White) – Replaces Wood
Vinyl Ceiling (White) & Sp Cover (Black)
Vinyl Walls (White) – Replaces Wood
Insulated Walls (R3) & Ceiling (R6)
Insulated Walls (R6) & Ceiling (R12)
40″ Tall Carpet on Walls
Floor Options
Black Coin Floor, Ramp, & Transition
Aluminum Extruded Floor, Ramp, & Transition
60″ Full Transition Flap with Adjustable Bumpers
In-Floor Storage – 15″ x 36″ x 7″
5,000 lb Winch with Remote
Door/Window Options
42″ x 32″ Slider Window with Shade (CS) (450 Only)
42″ x 32″ Slider Window with Shade (RS) (N/A with PED) (450 Only)
Exterior Options
Aluminum Slide Out Step (N/A 16′)
12V Awning with LED (15′) – 16′ Trailer
12V Awning with LED (16′) – 20′ Trailer
12V Awning with LED (20′) – 24’/28′ Trailer
Electric Tongue Jack (3,500 lb)
(2) Scissor Jacks (5,000 lb)
Exterior Grab Handle
(2) Bogey Wheels
Tongue Storage Compartment
Safety Options
Fire Extinguisher
Smoke Detector
Off-Road Motorcycle Package
- (1) Fold-Down Bench
- (1) Double Helmet Holder
- (2) Angle Wheel Chocks
- (1) Premium Strap Hanger
- (8) Eyebolt Anchors
- (2) 18″ x 24″ Upper Cabinets with Poly Doors
- (1) Deep Floor Bin
- (1) Door/Wall Caddy – Mini
Race Package
- (4) Single Coat Hooks
- (8) Wall Ties
- Premium Strap Holder
- Floor Jack Holder
- Dual Helmet Holder
- (2) Fuel Jug Holders
- Door/Wall Caddy
- Cord Hanger
Show Car Package
- (8) Wall Ties
- Premium Strap Holder
- Floor Jack Holder
- (2) 12” x 24” Upper Cabinets- Poly Door
Relax Package
- Roll Over Sleeper Sofa
- 30” Interior/Exterior Fold Table
- Cup Holder
Half Bath Package
- 12v Dry Flush Toilet
- Upper Cabinet w/ Privacy
- Portable Privacy Tent
- Lower Sink Cabinet
Small 12” x 24” Wall Cabinet with Net
Small 12” x 24” Wall Cabinet with Poly Door
Medium 18” x 24” Wall Cabinet with Net
Medium 18” x 24” Wall Cabinet with Poly Door
Medium 24” x 24” Wall Cabinet with Net
Medium 24” x 24” Wall Cabinet with Poly Door
Large 36” x 24” Wall Cabinet with Net
Large 36” x 24” Wall Cabinet with Poly Door
Large 48” x 24” Wall Cabinet with Net
Large 48” x 24” Wall Cabinet with Poly Door
Large 24” x 48” x 12” w/ Poly Door - No Divider
Large 24” x 48” x 12” w/ Net - No Divider
48” Wall Shelf
24” x 36” x 18" Convection Microwave
24” x 36” x 18” Single Drawer
24” x 36” x 18” 4 Drawer
24” x 36” x 18” Sink (Self-Contained Plumbing)
34” x 36” x 18” 6.7 Stō Wedge Only
38” x 36” x 18” Sink & Convection Microwave (Self-Contained Plumbing)
38” x 36” x 18” Cooler Slideout
30” x 45" Folding Dinette Table, Solid Surface
36” x 30” x 18” Table Wall Floor Mount, Composite
36” x 30” x 18” Table with Interior or Exterior Wall Mount, Solid Surface
45” x 36” x 18” Table with Interior or Exterior Wall Mount, Composite
30" x 18" Table with Interior or Exterior Wall Mount, Solid Surface
45" x 18" Table with Interior or Exterior Wall Mount, Solid Surface
72" x 18" Table with Interior or Exterior Wall Mount, Solid Surface
38” Pedestal Reclining Swivel Chair - Black
Premium Folding Chair
Rollover Sleeper Sofa, Black
Rollover Sleeper Sofa, Grey
Fold-Down Bench
Folding Wall Bunk
Broom Holder
Cord Hanger
Deep Floor Bin - Single Fuel Jug Rack
Door/Wall Caddy
Double Cup Holder
Double Helmet Holder
LifeTrac Anchor Kit (x4)
Floor Jack Holder
Jack Stand Holder
Mini Holder
Multi Coat Hanger
Narrow Floor Bin
Premium Strap Hanger
Single Coat Hook
Strap Hanger
Wheel Chock
Mini Wall/Door Caddy
