Rōm 800/900 – Stacker 22′, 24′ + 26′

Built for the Long Haul

No matter how often you hit the road or what you decide to bring along, the Rōm Stacker will get you there. It’s equipped with plenty of space and storage so you can haul multiple vehicles, including cars, ATVs, motorcycles and other toys. Available in several lengths; shorter models ideal for hauling behind an RV.

Sizes
Available in 22', 24', 26'
Basemodels
Choose the perfect fit from 3 models

Configurations

Available in 22', 24' or 26'

8.5' x 22'

View Details
Axle Rating
(2) 7,000 lb
GVWR
15,400 lb
Curb Weight (800/900)
6,800 / 6,890 lb
Payload (800/900)
8,600 / 8,510 lb
Axle Type
Torsion
Overall Length
27' 3 1/8"
Overall Width
102"
Overall Height
13' 5"
Interior Length
22' 2"
Interior Width
97 5/8"
Interior Height
135"
Minimum Ground Clearance
9 3/4"
Rear Door Opening Width
90"
Rear Door Opening Height
90"
Tongue Length to Center of Ball
62"
Center of Coupler to Corner Radius
88"
Width Between Wheel Wells
80"
Brakes
4 Wheel Electric
Tire Size
235/85/16 LRG
Hitch Height to Top of Ball
20 15/16"
Hitch Ball Size
2 5/16"
Floor Crossmembers
16" OC
Wall Studs
16" OC
Ceiling Crossmembers
16" OC

8.5' x 24'

View Details
Axle Rating
(3) 6,000 lb
GVWR
19,800 lb
Curb Weight (800/900)
7,150 / 7,490 lb
Payload (800/900)
12,650 / 12,310 lb
Axle Type
Torsion
Overall Length
29' 3 1/8"
Overall Width
102"
Overall Height
13' 5"
Interior Length
24' 2"
Interior Width
97 5/8"
Interior Height
135"
Minimum Ground Clearance
9 3/4"
Rear Door Opening Width
90"
Rear Door Opening Height
90"
Tongue Length to Center of Ball
62"
Center of Coupler to Corner Radius
88"
Width Between Wheel Wells
80"
Brakes
6 Wheel Electric
Tire Size
235/80/16 LRE
Hitch Height to Top of Ball
20 15/16"
Hitch Ball Size
2 5/16"
Floor Crossmembers
16" OC
Wall Studs
16" OC
Ceiling Crossmembers
16" OC

8.5' x 26'

View Details
Axle Rating
(3) 6,000 lb
GVWR
19,800 lb
Curb Weight (800/900)
7,450 / 7,625 lb
Payload (800/900)
12,350 / 12,175 lb
Axle Type
Torsion
Overall Length
31' 3 1/8"
Overall Width
102"
Overall Height
13' 5"
Interior Length
26' 2"
Interior Width
97 5/8"
Interior Height
135"
Minimum Ground Clearance
9 3/4"
Rear Door Opening Width
90"
Rear Door Opening Height
90"
Tongue Length to Center of Ball
62"
Center of Coupler to Corner Radius
88"
Brakes
6 Wheel Electric
Tire Size
235/80/16 LRE
Hitch Height to Top of Ball
20 15/16"
Hitch Ball Size
2 5/16"
Floor Crossmembers
16" OC
Wall Studs
16" OC
Ceiling Crossmembers
16" OC

The features you need most

All Standard Features

  • Frame Features
  • Spread Axle
  • 16” Wheel – 8 Lug Aluminum Rim
  • Extended Tongue
  • 16” O/C Sidewalls
  • 16” O/C Floor – Chassis
  • 16” O/C 1” x 2” Roof Members
  • 6,000 lb Rear Ramp Door
  • Transition Flap – 16" Black Coin Flooring
  • Stainless Steel Rear Paddle Latches (on Ramp Door)
  • Bogey Wheels
  • 4 Bolt Coupler – Flat Front Tongue
  • Winch Plate
  • Interior Height 11’ 4”
  • Pod Jacks – Stabilizing
  • Spare Tire Mount Backer (Attic roadside - front)
  • Girard Lateral Arm Prep for 20’ Awning
  • Hydraulic Tongue Jack
  • Exterior Features
  • ATP Gravel Guard (48”)
  • Screwless Exterior (0.050”) Metal
  • One-Piece Aluminum Roof
  • DOT Tape
  • Cast Corners – Polished
  • Upper & Lower Trim – 4”
  • Stainless Steel Front Corner & Top Radius Trim
  • Stainless Steel Rear Vertical Corners
  • Brushed Fenderettes
  • Mid Ship Lights and Turn Signals
  • Color Matched – Rear Header
  • Wired Rear Camera Prep – Voyager
  • Interior Features
  • Black TPO Floor and Ramp
  • Aluminum Walls and Ceiling – (0.030”) – White
  • 0.125” ATP Attic
  • Attic Tiedowns – 4-Rope Rings
  • 36” Entry Door – 22’ & 24’ Model
  • 48” Entry Door – 26’ Model
  • Slide In/Slide Out Step
  • Upper and Lower Cabinets
  • LED Strip Lighting (Under Cab and Lift)
  • Premium Escape Door – 72”
  • Stacker Cove – Black
  • 15 Amp Exterior Motorbase w/ Interior GFCI & (1) Recept
  • 55 Amp Convertor/Charger
  • (2) 14” LED Light – Under Attic With Switch
  • (2) AGM Batteries
  • (6) 14” LED Ceiling Lights – (2) 3-Way Switches
  • 14” Stacker Lift With Removable Inserts
  • Stacker Lift Control – Wall Mounted Front & Rear

All Packages

  • Plus
  • Perimeter Skirting
  • Polished Fenderettes
  • Lower Trim – 7”
  • 50 Amp Breaker Box w/ 60 Amp Converter
  • Power Cutoff Switch – Manual
  • (3) Interior Outlets – 15 Amp
  • (1) Exterior Outlet – 15 Amp
  • Wall Airline Track Segment
  • Attic Tie Downs – 2 Rows A-Track
  • (4) Floor Mounted Swivel D-Rings
  • Stainless Steel Rear Header and Spoiler
  • (2) Exterior Curbside Scene Lights
  • (3) AGM Batteries
  • In-Floor Battery Box – (3) Batteries
  • Exterior Docking Lights
  • 40” Bedrug – Interior Sidewalls
  • High Visibility Rear Light Package: (1) Pair Backup Lights Diagonal – Ramp Door, (2) Pair Tail Lights Diagonal – Ramp Door, (3) Pair Tail Lights Diagonal – Rear Header, (2) Extra Clearance Lights – Lower, (4) Extra Clearance Lights – Upper
